Discriptions
Specifications:
ENGINE:
- Type: 3 Cylinder, Liquid-cooled, Diesel, Naturally Aspirated (NA), Indirect Injection (IDI)
- Model (Tier 4): MHI
- Gross Engine HP: 24.6 hp
- PTO HP: 19.2 hp
- Rated Speed (RPM): 2,500 RPM
- Displacement: 80.4 cubic inches
- Fuel Tank Capacity: 10.6 gallons
- Alternator: 12V – 50 Amps
DRIVE TRAIN:
- Transmission Type: Synchro Shuttle
- Number of Speeds: F12 X R12 (12 Forward, 12 Reverse)
- Brakes: Wet, Multi-disc
- Steering: Hydrostatic Power Steering
PTO (Power Take-Off):
- Type: Independent
- Rear PTO Speed: 540 RPM (Standard)
HYDRAULIC SYSTEM:
- Control System: Position
- Implement Pump Flow: 7.9 gallons per minute (gpm)
- Steering Pump Flow: 4.6 gpm
- Total Flow: 12.5 gpm
- 3-Point Hitch Category: Category I (CAT I)
- Hitch Lift Capacity at Hitch End: 1,808 lbs
- Remote Valves: Optional
DIMENSIONS:
- Overall Length (Frame to Link): 119 inches
- Overall Width with Tires: 66 inches
- Wheelbase: 66 inches
- Height to Top: 95 inches
TIRE SIZES:
- Agricultural (Ag) Front / Rear: 7 – 14 / 11.2 – 24
- Industrial (IND) Front / Rear: 27X8.50-15 / 43X16.00-20
- Versa Turf (VT) Front / Rear: 27X8.50-15 / 43X16.00-20
- Turf Front / Rear: 25X8.50-14 / 41X14.00-20
WEIGHT:
- Total Weight without Ballast: 2,985 lbs
