The MT3E Series provides a variety of horsepower ratings and transmissions to accommodate any customers needs. Those customers requiring value and power will find plenty of both in this robust series of LS tractor.
Specifications:
Engine
-
Type: Vertical Water-Cooled 4-Cycle Diesel Engine
-
Model (Tier 4): L3C19-T
-
Emission Standards: EPA & CARB Tier 4F, EU Stage IIIB
-
Engine HP (Gross): 55 HP
- PTO HP:
- 44 HP (Hydrostatic Transmission)
- 46.7 HP (Gear Transmission)
-
Rated Speed (RPM): 2,600 RPM
-
Displacement: 114.7 cu. in.
-
Fuel Tank Capacity: 13.7 gallons
Drive Train
-
Transmission: Synchro Shuttle / Constant Mesh
-
No. of Speeds: 8 Forward x 8 Reverse
-
Brakes: Wet, Multi-Disc
PTO
-
Type: Independent
-
Rear PTO RPM: 540 RPM
Hydraulic System
-
Control System: Position
-
Implement Pump Flow: 8.2 gpm
-
Steering Pump Flow: 4.8 gpm
-
Total Flow: 13.0 gpm
-
3-Point Hitch Category: CAT I
-
Hitch Lift Capacity: 2,910 lbs
-
Remote Valves: 2 pairs (Front), 1/2 pairs (Rear, Optional)
-
Steering: Hydrostatic Power Steering
Dimensions
-
Overall Length (Bumper to Link): 125 in.
-
Wheelbase: 68 in.
-
Overall Width with Tires: 74.8 in.
-
Height to Top of ROPS: 100 in.
Tire Sizes
-
Agricultural Tires (Front / Rear): 9.5-16 / 14.9-24
-
Industrial Tires (Front / Rear): 10.0-16.5 / 17.5L-24
-
Turf Tires (Front / Rear): 29 x 12.50-15 / 44 x 18.00-20
-
Narrow Agricultural Tires (Front / Rear): 7.0 – 14 / 9.5 – 24
Weight
-
Total Weight without Ballast: 3,724 lbs
