LS TRACTOR MT473PS – 73HP, POWER SHUTTLE

Features:

• MT4 redesigned with new LS Family Look. New hood design allows for improved engine performance and serviceability
• LED Lamps for all models provide better illumination for more efficient work in darker operating conditions
• Larger tire size options which provide better grip and traction with lower ground pressure.
• 15% more space in new cab design than previous model allows for more comfort and convenience in the same footprint. Additionally, the redesigned cab offer improved access to key components for easier diagnosis and routine maintenance
• Improved high back for seat with wider and improved cushion for greater operator comfort
• Enhanced lift height (up to 132.9” in max height mode) and capacity (3,487 lb in max power mode) for front loader (LL5001) with standard self leveling bucket
• Standard 2 sets of remote valves. Adds functionality and improves ease of use by allowing attachment of hydraulically controlled implements without the high, additional costs like others in its class to add the remotes as options.
• Extendable lower links. Category 2 with hitch lift capacity of 4,079 lbs. allows easier attachment of a wide variety of implements.
• Standard 3rd function button on joystick

Specifications:

Engine

• Type: Vertical Water-Cooled 4-Cycle Diesel Engine
• Model (Tier 4): L4C25-T
• Engine HP (Gross): 73 HP
• PTO HP: 62.9 HP
• Rated Speed (RPM): 2,500 RPM
• Displacement: 152.85 cu. in
• Fuel Tank Capacity: 24.3 gal

Drive Train

• Transmission Type: Electro Power Shuttle
• Number of Speeds: F16 x R16
• Brakes: Wet, Multi-disc
• Steering: Hydrostatic Power Steering

PTO

• Type: Independent
• Rear RPM: 540, 540E (Standard)

Hydraulic System

• Control System: Position / Draft
• Implement Pump Flow: 14.5 gpm
• Steering Pump Flow: 6.6 gpm
• Total Flow: 21.1 gpm
• Category (3-Point Hitch): CAT II
• Hitch Lift Capacity (at Hitch End): 3,483 lbs
• Remote Valves: 2 Pairs (Front), 2 Pairs (Rear)

Dimensions

• Overall Length (Frame to Link): 135 in
• Overall Width (with Tires): 72.6 in
• Wheelbase: 83.1 in
• Height (to Top): 113.9 in

Tire Size Options

• Agricultural Front/Rear: 9.5–24 / 16.9–28
• Industrial Front/Rear: 10.5/80×18 10PR / 19.5L×24 8PR
• Large Agricultural Front/Rear: 11.2–24 / 16.9–30
• R14 Front/Rear: 320-85R20 119D / 420/75R34 142D

Weight

• Total Weight (without ballast): 5,423 lbs
