Discriptions
Through Ventrac’s advanced engineering and design efforts, the best mix of machine performance, operator experience, and durability has come together in the new 4520 tractor.
Ventrac has become the #1 choice for versatility for ground’s care professionals. Combining the perfect blend of peak power and agility with front-mounted attachments for superior visibility, pivoting frame for maneuverability, and proper weight distribution for balance and stability, it’s time to elevate your Ventrac experience to a whole new level.
Specifications:
- Sales Model: 4520P
- Description: KN, 4520P Kawasaki FD851D
- Product Type: Tractor
Engine
- Manufacturer: Kawasaki
- Model Number: FD851D DFI
- Horsepower: 31 hp
- Peak Torque: 47.1 ft-lbf
- Displacement: 824 cc
- Number of Cylinders: 2
- Cooling System: Liquid-cooled
- Fuel Type: Gasoline
- Fuel Capacity: 6 gallons
- Estimated Fuel Economy: 1.2 gallons per hour (with a 60-inch mower)
Drive System
- Drive Type: AWD (All-Wheel Drive)
- Travel Speed (Low Range): 5 mph forward, 4 mph reverse
- Travel Speed (High Range): 10 mph forward, 8 mph reverse
Dimensions
- Overall Width: 48.5 inches
- Overall Length: 81.5 inches (standard hitch, ROPS up)
- Height:
- ROPS Up: 68 inches
- ROPS Down: 54 inches
- Wheelbase: 45 inches
- Weight:
- With 3-point hitch: 1700 lbs
- Without 3-point hitch: 1620 lbs
- Ground Clearance: 5 inches
- Turning Radius: 39 inches
- Oscillation Amount (@ wheel): 7.5 inches
Tires
- All Terrain (Standard): 22x12-8
- Turf (Standard): 22x11-10
